Digital Product Passport

Driver elements

Infinite Acoustics Tweeter 1" driver D25 Infinite Acoustics

HiFi high quality silk dome tweeter

Purchase Now

Product Code

CMPN0113-P

Method of Manufacturing

City

Malmo

Country

Sweden

Manufacturing Info https://www.lostboyslab.shop/products/infinite-acoustics-dome-tweeter-1 Data Sheet Download
Product Height (mm)
42.5
Product Depth (mm)
42.5
Product Diameter (mm)
99.7
Product Weight (Kg)
0.7
Batch or Lot Number
Vellinge-SWE01
taric_code
8518 29 00 00
Ageis Vault subdomain TEAM ID https://36.aegis-vault.eu

Electro-mechanical, Thiele-Small, and CRMA Article 27 permanent magnet specifications for loudspeaker transducer drivers (Tweeters, Midranges, Woofers)

Driver Category / Type (N/A)
Tweeter
Nominal Impedance (Ω)
6
DC Voice Coil Resistance (Re) (Ω)
5.2
Resonance Frequency (fs) (Hz)
1200
Sensitivity (SPL) (dB)
91
Continuous Power Handling (RMS) (W)
50
Voice Coil Diameter (mm)
25.4
Total Q Factor (Qts) (N/A)
0.85
Effective Moving Mass (Mms) (g)
0.35
Motor Force Factor (BL) (N/A)
2.1
Diaphragm / Cone Material (N/A)
Silk diaphragm
Suspension / Surround Material (N/A)
Integrated silk surround
Voice Coil Former Material (N/A)
Aluminium (ASV)
Voice Coil Conductor (N/A)
CCAW
Magnet Motor Material (N/A)
Ceramic Strontium Ferrite
Magnet Mass (g)
228
CRMA Art. 27 Scope Trigger (≥ 0.2 kg) (N/A)
Yes
Ferrofluid Dampened / Cooled (N/A)
Yes
Air Gap Flux Density (N/A)
1.2

Category Name

Driver elements

Country

Sweden

City

Malmö

Email [email protected] Website https://www.infinite-acoustics.com/
Classification System
ETIM
Classification Code
8518 29 00 00
Classification Version
10
classification URI link
https://viewer.etim-international.com/class/EC000652
Classification Title
ETIM 2.0
Classification Authority
ETIM international
Batch Production run
TW-2024
Category Logo

No record found for support resources

Assembly Support image

Home of the Goosebumps

Faithfully tracing the shoreline, this iconic stretch of the Pacific Coast Hwy links the infinite ocean to an endless matrix of busy highways. This location allows us to feed our additive manufacturing pipeline with ocean plastic from the Pacific waste patch and tire rubber from the freeways to the East. The PCH, as a result of this, becomes our natural fulcrum.

Company Name

Infinite Acoustics

Country

Sweden

City

Malmo

Lead Engineer

Stefan Larsson

Contact Email [email protected] Corporate Website https://www.infinite-acoustics.com/
operator_id_scheme
559389-9445
operator_id
SE559389944501
taric_code
8518 21 00
operator_name
infinite Acoustics
geo_uri
55.458477773073305, 13.01676033545338
biz_location
whattio:bizloc:Vellinge
read_point_default
whattio:readpoint:Vellinge
Ageis Vault installed
Yes
