Digital Product Passport
Product Data
incendo ONE shield PCB complete w TFT Display Arduino pre-built
The complete electronics kit for the top panel with LED, TFT display, PCB mounted push buttons and connectors to the Arduino UNO R2 below.
Product Code
PROD0671
GTIN number
-
Place of manufacturing
Los Angeles
Country of manufacturing
United States of America
Spare Parts
Spare Part Information
TFT Display 2.0" 320x240 Color IPS with microSD Card Breakout - ST7789 EYESPI
The 2.0" display has 320x240 color pixels. Unlike the low cost "Nokia 6110" and similar LCD displays, which are CSTN type and thus have poor color and slow refresh, this display is a true TFT! Not only that, but its an IPS display for vivid color and high-angle visibility. The TFT driver (ST7789) can display full 18-bit color (262,144 shades), but almost all drivers will use just 16-bit color. The TFT will always come with the same driver chip so there's no worries that your code will not work from one to the other.
LED Red 1500 mcd
VINKEL 30 LJUSSTYRKA 1500 mcd FÄRG Röd STRÖM 25 mA FRAMSPÄNNING 2 V LINS Färgad diffus STORLEK Rund ø5mm VÅGLÄNGD 625 nm
Resistor 0.25Watt Generic
Generic Resistor with 0.25 Watts power, available in various sizes of resistance
Push Button PCB 12x12x5
Tangentbordsströmställare för kretskortsmontage med svart tryckknapp i plast. Storlek: 12 x 12 mm Knappens diameter: 7 mm Höjd: 5 mm (bas 3 mm) Slaglängd: 0.25 mm Max ström: 50 mA Max spänning: 24V DC
Screw M3x10 mm black carbon steel with hexagon socket cap self tapping
M3 x 10 self tapping screws allen
M2.6x6 Cross Pan Head Self Tapping Screw
1. Stainless steel material provides high strength and good durability, available in harsh environment. 2. Precision threads can easily go through various material like plastic, wood, soft metal and more. 3. High in hardness, not easy to deform.
NFC Read write Module PN 532
NFC write and Read module is connected to the incendo shield through I2C
Sub-products
The Arduino UNO WiFi Rev.2 is the easiest point of entry to basic IoT with the standard form factor of the UNO family. Whether you are looking at building a sensor network connected to your office or home router, or if you want to create a Bluetooth® Low Energy device sending data to a cellphone, the Arduino UNO WiFi Rev.2 is your one-stop-solution for many of the basic IoT application scenarios.
Spare Part Name
- Amount required:
- Part SKU:
- Version:
- Manufacturing method:
Material
Main Material
Material name
FR-4 composite material
Material brand
PCB Way
Material code
fiberglass cloth with an epoxy resin binder.
Country of origin
China
Secondary Material
No record found for secondary material
Support
Recycling
Bioderived
No
Biodegradable
No
Material chemical name
fiberglass cloth with an epoxy resin binder.
Manufacturing
whatt.io
We are building the physical metaverse and we strive to become the global leader in revolutionising product lifecycle management through innovative technology, with a commitment to ending waste and plastic pollution. We are building the physical metaverse and we strive to become the global leader in revolutionising product lifecycle management through innovative technology, with a commitment to ending waste and plastic pollution. We envision a future where seamless access to product information, secure authentication, and sustainable practices are the norm, leading to a significant reduction in waste generation and the preservation of our environment. By empowering businesses and consumers with knowledge, we strive to create a world where every product is valued, waste is minimised, and the circular economy thrives and paves the way for a cleaner and greener planet.
Name
whatt.io
Country
United States of America
Country
United States of America
